Memory-type Pressure Gauge
Product Overview
Section titled “Product Overview”The Memory-type Pressure Gauge has an independent measuring element and a memory pointer. The black pointer indicates the current pressure, while the red pointer remains at the last indicated pressure position to provide a memory function.
Product Principle
Section titled “Product Principle”When pressure acts on the measuring element, the black pressure display pointer drives the red memory pointer to the pressure indication. When there is no pressure, the black pointer returns to zero while the red pointer remains at the previous pressure position. To reset the record, rotate the central knob counterclockwise to align the red pointer with the black pointer.
Technical Specifications
Section titled “Technical Specifications”| Item | Specification |
|---|---|
| Model | YB-100 |
| Measurement range | 0-0.1, 0-0.16, 0-0.25, 0-0.4, 0-0.6, 0-1, 0-1.6, 0-2.5, 0-4, 0-6, 0-10, 0-16, 0-25, 0-40, 0-60, -0.1-0, -0.1-0.06, 0-0.15, 0-0.3, 0-0.5, 0-0.9, 0-1.5, 0-2.4 MPa |
| Accuracy grade | 1.0, 1.6, 2.5 |
Information Required for Inquiry
Section titled “Information Required for Inquiry”- Required measuring range and accuracy grade.
- Whether maximum pressure memory indication is required.
- Medium and installation requirements.
Related Products
Section titled “Related Products”- Three-pointer pressure gauge.
- YB series stainless steel pressure gauge.
Product Downloads
Section titled “Product Downloads”View this product PDF catalogue online, or return to the Pressure Gauge downloads page for related documents.
