Three-pointer Pressure Gauge
Product Overview
Section titled “Product Overview”The Three-pointer Pressure Gauge is designed to provide production operators with visual prompts based on process conditions. It uses three pointers to show the actual pressure and the allowed operating range.
Applications
Section titled “Applications”- Process pressure monitoring where upper and lower operating limits must be visible.
- Production operation prompts for safe process control.
- Applications where operators need to identify abnormal pressure quickly.
Product Features
Section titled “Product Features”- Black pointer indicates the actual measured pressure.
- Red pointer indicates the maximum allowable pressure.
- Green pointer indicates the minimum allowable pressure.
- If the black pointer exceeds the red or green pointer range, the process condition is abnormal.
Technical Specifications
Section titled “Technical Specifications”| Item | Specification |
|---|---|
| Models | YB-100, YB-150, YB-200, YB-250 |
| Measurement range | Vacuum, compound and positive pressure ranges from -0.1 MPa to 0-1000 MPa |
| Accuracy grade | 1.0, 1.6, 2.5 |
Information Required for Inquiry
Section titled “Information Required for Inquiry”- Required model and pressure range.
- Accuracy grade.
- Maximum and minimum allowable process pressures.
- Medium, material and installation requirements.
Related Products
Section titled “Related Products”- YB series stainless steel pressure gauge.
- YBN series vibration-resistant stainless steel pressure gauge.
Product Downloads
Section titled “Product Downloads”View this product PDF catalogue online, or return to the Pressure Gauge downloads page for related documents.
